Transport Height |
690 mm |
|
Width |
1,626 mm |
|
Tramming Length |
3,945 mm |
|
Max Ground Clearance |
250 mm |
|
Weight |
4,000 kg ref. |
|
Stability (incline & cross grade) |
12.5 degrees |
|
Max tramming speed |
1.5 kph |
|
Electric Motor |
22 kW, 525/1000 VAC |
|
Hydraulic System |
210 Bar 90 lpm 70 lt |
|
Drill Mast |
CFP180 Feed Frame |
|
Feed Frame Length |
3,132 mm |
|
Max Horizontal Drill Height |
1,700 mm |
|
Min Seam Height |
800 mm |
|
Max Drill Travel |
1,800 mm |
|
Max Feed Thrust |
450 kg.f |
|
Hydraulic Drifter (Hardrock) |
Doofor DF530XS |
|
Power |
10 kW |
|
Max Torque |
175 Nm |
|
Max Speed |
250 rpm |
|
Chuck Size |
R32 |
|
Max Water Pressure (flushing) |
10 Bar |
|
Min Water Pressure (flushing) |
5 Bar |
|
Rotary Drill* (Softrock) |
S3 |
|
Max Torque |
375 Nm |
|
Max Speed |
600 rpm |
|
Chuck Size |
22 mm Hex |
