Transport Height |
1,385 mm |
|
Width |
1,995 mm |
|
Length |
5,330 mm |
|
Minimum Ground Clearance |
255 mm |
|
Weight |
4,150 kg ref. |
|
Stability (incline & cross grade) |
12.5 degrees |
|
Max tramming speed |
1.5 kph |
|
Flameproofing (optional) |
Ex d 1, Zone 1, 150°c |
|
Electric Motor |
22 kW |
|
Diesel Engine |
34 kW |
|
Hydraulic System – Max Pressure |
210 Bar 90 lpm 275 lt |
|
Drill Mast |
CFF 240 Feedframe |
|
Feedframe Length |
3,132 mm |
|
Max Horizontal Height |
4,010 mm |
|
Min Horizontal Height |
120 mm |
|
Max Drill Travel |
2,200 mm |
|
Max Feed Thust |
450 kg.f |
|
Hydraulic Drifter |
Doofor DF530S |
|
Power |
10 kW |
|
Max Torque |
175 Nm |
|
Max Speed |
250 rpm |
|
Chuck Size |
R32 |
|
Max Water/Air Pressure (flushing) |
8 Bar |
