Engineered for maximum holes per day
Optimised for repetitive, high-accuracy drilling
High-frequency DTH hammer compatibility (max. hole size 250mm
dia.; max. hole depth 2,400mm)
Minimal setup time between holes
Low total cost per hole drilled
Adjustable feed pressure control to suit site conditions
Variable rotation speed and torque rotation drive
Heavy duty rotary head with high torque and high / low gear ration
Narrow guage for ease of transport
On screen drill mast verticality indicator
On screen, adjustable hole depth indicator
Digital data logging
Low ground pressure tracks for soft soil
Tramming gradeability up to 20 degrees (mast lowered only)
Air cooled diesel engine
| General Dimensions | |
| Length (transport) | 4630 mm |
| Width | 1940 mm |
| Height (transport) | 2190 mm |
| Weight | 4400 kg |
| Ground clearance | 385 mm |
| Performance | |
| Maximum Tramming Speed | 1.85 kph (LR) / 3.7 kph (HR) |
| Maximum Hole Depth | 2400 mm |
| Maximum Hole Size ** | 250 mm |
| Maximum incline (tramming) | 20 deg. |
| Hydraulics | |
| Maximum Hydraulic System Pressure | 190 Bar |
| Maximum Hydraulic System Flow | 101 lpm |
| Blast Fan Cooler (12VDC) | S5 |
| Cyclone Oil Reservoir | 20 GPM |
| Diesel Power | |
| Kirloskar air-cooled HA494 engine, 12VDC Control System | 46 kW @ 2300 rpm (sea level) |
| Diesel Tank Capacity | 120 ltr |
| Drill Mast | |
| Mast Length | 4630 mm |
| Maximum Drill Travel | 3100 mm |
| Maximum Torque Rating | 12000 N.m |
| Maximum Feed/Retract Thrust (chain) | 3000 kg.f |
APPLICATION
Designed specifically for utility-scale solar farms
DTH hammmer drilling & Auger drilling of solar
post holes
