Physical Dimensions |
Drag steer option |
Crawler tracks option |
|
Height |
1160 mm |
850 mm* |
|
Width |
2330 mm |
2470 mm* |
|
Length |
3720 mm |
3950 mm* |
|
Weight |
4500 kg |
6950 kg |
|
Min Ground Clearance |
290 mm |
|
|
Electrics |
||
|
Flameproofing |
Ex d 1, Zone 1, 150°C |
|
|
Electric Motor |
55 kW, 525/1000 VAC |
|
|
Hydraulic System |
||
|
Max Operating Pressure |
210 bar |
|
|
Max Oil Flow
|
220 lpm |
|
|
Tank Capacity
|
300 ltr |
|
|
Feedframe |
||
|
Length |
1815mm |
|
|
Max Drill Travel |
1000mm |
|
|
Drill Rod System |
BQ/BT |
|
|
Chuck & Rod Holder |
||
|
Chuck Type |
Hyd. Open / Mech. Close |
|
|
Rod Holder |
Hyd. Open / Mech. Close |
|
|
Max Opening Chuck & Rod Holder |
58 mm |
|
|
Jaw Qty (Rod Holder) |
1 |
|
|
Jaw Qty (Chuck) |
3 |
|
|
Jaw Type |
Tungsten Carbide |
|
|
Water Flushing |
High Pressure Piston Pump |
|
|
Max Flow |
115 lpm @ 520 rpm |
|
|
Max Pressure |
68.9 bar |
|
